Structural Strength

 TCM series beds produced by TCM Foundry Division is the heaviest of any comparable Swiss-type on the market. Much of this weight is attributed to the extremely rigid and stable base casting and tool stand, which reduces vibration and provides thermal stability critical to maintaining tight tolerances on workpieces.

TCM series weight 3,500kg

CASTING BED.jpg
BED 1.png

Ensures the accuracy and durability required for ultimate flatness and verticality of key components.
Accuracy. Scraping is performed to align components within a millionth of an inch to allow consistent and strict tolerances.

8 to 10 contacts per square inch of flatness are created to prevent shaking, add balance when tightened, and give parts true flatness

HAND SCRAPING.jpg





One of the common complaints we hear about Swiss-types is the lack of interior room available for setup.



We know that a dark, cramped interior space is not the ideal environment for anyone. We responded by engineering the cabinet of TCM series Swiss type auto lathes to be



as spacious as possible within the machine’s minimal footprint.

INTERIOR ROOM.jpg
